RV TV Mount with Articulating Arm

It’s time to camp in style with the RV TV Mount with Articulating Arm (MOUNT-VWRV3) from VIVO! Made from sturdy plastic polymer and steel, this mount supports screens weighing up to 22 lbs with 100x100mm VESA mounting patterns. Designed for use inside an RV or camper, this product will hold your TV safe and secure. A wide variety of hardware is included to ensure fitment with different TVs, and the 2-piece bracket design provides fast and easy screen installation and removal for a hassle-free movie night experience!

• VESA Standard: 100x100mm
• Weight Capacity: 22 lbs
• Mounting Location: If mounting on an RV, locate the designated mounting location which should be pre-labeled by the manufacturer as TV BACKER or TV MOUNTING LOCATION
• Important Note: TV should always be removed from the wall and securely stowed away while the RV/Camper is in motion

• Material: Plastic Polymer VESA Plates, Steel Arm and Wall Plate
• Bracket Dimensions: 5.8” x 5.5”
• Base Plate Dimensions: 5.3” x 6.3”
• Maximum Extension: 16.5”
• Articulation: 180° swivel, +30° to -30° rotation
• Collapsed Dimensions: 11” x 2.3” x 7”
• Arm Thickness: 1.2” x 0.8”

• Assembly Manual PDF
